Introduce the latest version of PCB Prototyping machine CMPCBM-01 which is a unique solution to design and develop prototype PCBs in the Electronic Laboratory without the use of any toxic chemicals. The CMPCBM-01 is the best choice of your PCB Lab to design & develop Prototype PCBs.
| ● The CMPCBM-01 offers a working area of 330x220mm, making it suitable for detailed PCB prototyping. |
| ● Powered by a 25,000 RPM brushless motor, it ensures precision and efficiency. |
| ● The robust cast aluminum base provides stability during operations. |
| ● X/Y axis stepper motors allow smooth travel at speeds of up to 60mm/sec. |
| ● Compact and portable, its dimensions are 395x330x375mm, with a weight of 20kg. |
| Working Area | : | 330x220mm |
| Min Drill hole size | : | 0.3mm |
| Min cutting trace/space | : | 0.1mm (4mil) |
| X/Y travel speed | : | 60mm/sec (max) |
| Spindle speed (RPM) | : | 25000 |
| Spindle Motor | : | Brushless Motor |
| Machine Base | : | Cast Aluminum |
| Tool Change | : | Manual |
| Tool Holder Collet | : | 2mm, 3mm |
| X/Y driver | : | Stepper motor |
| Dimensions (W x H x D) | : | 395 x 330 x 375mm |
| Weight | : | 20Kg |
| Power Consumption | : | 220VAC, 50Hz |
